This JBL VRX powered 12″ two-way line-array speaker system rental with DSP is the ideal line array choice when performance is vital yet venue size doesn’t call for the very long-throw characteristics of larger line arrays. Lightweight and compact, it makes set-up fast and easy, and it pairs nicely with JBL’s VRX918SP powered subwoofer.
The speaker’s built-in JBL Drivepack® DPC-2 amplifier module – designed by Crown – provides 1750 watts of peak power. Has DSP module that provides system optimization and EQ functionality.
The enclosure houses JBL’s exclusive neodymium magnet Differential Drive® woofer for high-power capacity and three 2408J Annular Ring Diaphragm HF drivers, the latest in JBL Professional compression driver design. A Constant Curvature waveguide ensures unprecedented array coherence.
Integral rigging hardware makes it easy to connect enclosures and an optional array frame, or the dual-angle pole socket may be preferred for aiming flexibility. Array shading is made possible by the VRX932LAP’s Array Configuration Selector.
Manufacturer Specs
General
Power Rating
Peak: 1750 Watts
Continuous: 875 Watts
DPC-2 Output (Continuous IED shaped pink noise into rated load impedance)
LF: 750 watts
HF: 125 watts
DPC-2 Output Section: LF Dual-Bridged Technologyu2122, Class D
Frequency Range: 57 Hz – 20 kHz (-10 dB)
Frequency Response: 75 Hz – 20 Hz ( /-3db)
Maximum Peak Output: 136 dB SPL at 1m
Coverage Pattern: 100 x 15 nominal
Audio Input Connector: XLR with loop through
User Control: Input Attenuator (0-16 dB)
Signal Processing: DSP based, resident in Input Module
Drivers
LF: 1 x JBL 2262FF, 12″ (305 mm) neodymium magnet
HF: 3 x JBL 2408J, 1.5″” (38 mm)
Power
Operating Range: 90 to 132 VAC or 216 to 264 VAC, 50/60 Hz
Connectors
AC Input: Neutrik PowerCon (NAC 3MPA)
Loop Through: Neutrik PowerCon (NAC 3MPB)
AC Current
120V: 6A per system
240V: 3A per system
Physical
Dimensions: 13.75″”H x 23.5″”W x 17.5″”D (349 x 597 x 444 mm)
Weight: 52 lbs (24 kg)
Enclosure: 25/15 mm, 11-ply birch plywood
Finish: Black DuraFlexu2122 finish
Grille: Powder coated, black, 16-gauge perforated steel with with acoustically transparent foam
Suspension/Mounting
Optional VRX-AF line array frame kit
10mm forged eyebolts
Internal dual-angle 36mm pole mount cup for pole or tripod mounting “”
