Product Weight: Luminaire, 43 lbs; external ballast,16.6 lbs
Dimensions: 25.8″H x 17.0″W with convex lens
Programmable Functions
Intensity Control: Internal mechanical douser.
Color Mixing System: Patented DICHROTUNE radial color changing mechanism features independent magenta, blue, and amber color control.
Beam Control: A selection of six easily interchangeable front lenses work with the internal diffusing mechanism to provide a variety of beam sizes and shapes. (Stipple lens comes in the standard model).
Pan and Tilt: Smooth, time-controlled continuous motion by way of a high-power stepper motor system capable of 0.3° resolution.
Range: Pan – 540°, Tilt – 270°.
Description
Source: MSR700/2 700W Arc Lamp Color Temperature 7200K
Power Requirements: 700W Arc 100-240VAC, 50/60Hz
Reflector: Precision parabolic glass reflector system with dichroic cold mirror coating.
Operational Temperature: -20° to 122°F
Cooling: Natural convection cooling supported by on-demand micro-fans for high temperature applications.
Control: Completely compatible with a variety of DMX512 lighting control consoles.
DMX Channels: 8-13 channels depending upon mode selected.
Mounting Position: May be mounted and operated in any orientation.
Spacing: Hangs on 19 inch centers
